Siemens HiPath 3000 Series - Hipath 3300 Board Power Requirement

Identifying System Power Requirements Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
D-10 HiPath 3000/5000 V9, Service documentation
power_calc.fm
HiPath 3300 Board Power Requirement
D.5 HiPath 3300 Board Power Requirement
Table D-9 Nominal Output of the HiPath 3300 Power Supply Units
Power Supply Unit Part Number Max. Nominal Output in W
5 V –48 V
UPSC-DR S30122-K7373-A900
S30122-K7373-M900
20.0
1
1 Nominal output = 40 W. Due to build-up of heat, not more than 20 W may be withdrawn.
53.0
Powerbox PB3000 with
LUNA2
S30177-U773-X with
S30122-K7686-M1
– 110
>
You must check whether the total power requirement of the boards used and the
workpoint clients connected exceeds the maximum possible output of the UPSC-DR
with or without Powerbox PB3000. A sample calculation is shown in Section D.7.
Table D-10 Board Power RequirementHiPath 3300
Board or Component Part Number Net Power Requirement in
W
5 V –48 V
BS3/1 S30807-H5482-X – 2.0
BS3/3 S30807-H5485-X – 3.0
CBRC (including subboards) S30810-Q2935-Z301 7.0 0.5
HXGR3 S30810-K2943-Z 10.0 –
IVMP8R S30122-K7379-Z100 2.6 0.3
Fan for HiPath 3300 – – 1.4
P DM1 S30807-Q5692-X100 – 5.0
SLAD8R S30810-K2956-X300 2.0 1.0
SLU8R S30817-K922-Z301 0.8 –
STLS4R S30817-K924-Z313 1.0 –
STRBR S30817-Q932-Z 0.5 –
TLA4R S30817-Q923-Zxxx 0.2 –
TMGL4R S30810-K2918-Z 5.7
1
1 Identified at a traffic flow of 0.8 Erlang
0.1
1
8SLAR S30810-K2925-Z 1.3 1.3
