Expanding and Upgrading HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
9-14 HiPath 3000/5000 V9, Service documentation
exup.fm
HiPath 3000Expanding
9.1.3.3 Installation Options
The Powerbox PB3000 can be installed as follows:
● in a 19-inch cabinet (see Section 9.1.3.8).
● mounted on a wall (see Section 9.1.3.7)
● on a desktop using four adhesive mounting feet
For information on the assembly kit for wall attachment or desktop installation, see Section
9.1.3.2.
9.1.3.4 Technical Specifications
9.1.3.5 UPS bridging time/charging time
USP bridging times and charging times when using the PB3000 with 48 V / 7 Ah batteries and
LUNA2 power supply (at maximal continuous current less than 2A, for all loads):
● Example PB3000 - HiPath 3300/3500
– UPS bridging time: >1 h 30 min
– Battery charging time: ~ 2 h
● Example PB3000 - HiPath 3800
– UPS bridging time: > 30 min
>
Use the power cable to ground the Powerbox PB3000. Fixed, separate grounding is
not required.
Table 9-2 Technical Specifications for PB3000
Powerbox PB3000 / Components Technical specifications
Powerbox PB3000
- including batteries and LUNA2 power supply
Weight when empty: 7.0 kg
Total weight: 21.0 kg (13.22
lb.)
Battery compartment - including 4 batteries Weight: 12.0 kg
Single battery (12 V / 7 Ah) Weight: 2.65 kg
LUNA2 power supply Weight: 2.0 kg
For further information on
LUNA2 power supply, see
Section 3.2.12
