Installing HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

4-120 HiPath 3000/5000 V9, Service documentation

inst_h3.fm

Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300

4.2.4.9 Configuration Notes

HiPath 3500: system overview and slots

Caution

For safety, operate HiPath 3500 only with the housing front closed. Always use dum-

my panels (C39165-A7027-B115) to close slots that are not equipped with boards.

Figure 4-66 HiPath 3500 - Slot Levels in the 19-Inch Housing

It is imperative that you observe the restrictions regarding TS2R installation.

Slot 4 Slot 5

Slot 8

Slot 9

Slot 6 Slot 7

Slots 1-3

Slot

levels:

5 (options)

4 (CBRC)

3 (Peripheralboards)

2 (Peripheralboards)

1 (Peripheralboards)
