Siemens HiPath 3000 Series

To Next Page

To Previous Page

inst_h3.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

4-121

Nur für den internen Gebrauch Installing HiPath 3000

Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300

HiPath 3300: system overview and slots

Caution

For safety, operate HiPath 3300 only with the housing front closed. Always use dum-

my panels (C39165-A7027-B115) to close slots that are not equipped with boards.

Figure 4-67 HiPath 3300 - Slot Levels in the 19-Inch Housing

Slot 4 Slot 5

Slots 1-3

Slot

levels:

3 (options)

2 (CBRC)

1 (Peripheralboards)
