Siemens HiPath 3000 Series - GEE12 (Not for U.S.), GEE16 (Not for U.S.), GEE50 (Not for U.S.)

Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-374 HiPath 3000/5000 V9, Service documentation
boards.fm
Options
3.4.8 GEE12 (not for U.S.), GEE16 (not for U.S.), GEE50 (not for U.S.)
Introduction
Each of the modules listed below supports four call-metering receiving units for recording and
preprocessing call charge pulses in HiPath 3550 and HiPath 3350.
The call charge detection channel is looped in the trunk and then routed to the TLA
Interfaces
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
Table 3-181 GEE12/GEE16/GEE50 (not for U.S.) Modules
Module Frequency Remarks
GEE 12 12 kHz also for Silent Reversal
GEE 16 16 kHz
GEE 50 50 Hz
Figure 3-138 GEE12, GEE16, GEE50 (not for U.S.) - Interfaces (S30817-Q951-Axxx)
To CO
LS
CB side
Board side
X2
X1
GEE module
to the TLA
X3
X4
1
10
1
8
X5
1 10
