Applications over IP
13.9.2 CSTA via IP
The Transmission Control Protocol (TCP) is used for CSTA via IP. A permanent connection is
set up. Data packet loss is detected and automatically corrected.
For HiPath 3000, the following number of server applications may be connected per system:
● up to one in HiPath 3300/3350, HiPath 3500/3550
● up to four in HiPath 3800
Restrictions may apply to applications that use certain services. For example, only one appli-
cation at a time can start the message registration function.
For an external application to address HiPath 3000/5000, it must know the TCP port (7001) of
the TCP/IP server implemented in HiPath 3000/5000 as well as the IP address. Data packets
sent from an application to HiPath 3000/5000 – that is, packets containing the HiPath IP ad-
dress, TCP port 7001, and protocol type TCP – are accepted for further processing.
HiPath 3000 V7 and later systems support CSTA monitoring of connections to ITSPs. This en-
ables call center applications, for example, to be used, even if SIP trunks are used.
Model-specific data
LIM / LIMS
LIM/LIMS is released in HiPath 3800 for administration, fault management and accounting. No
other features or protocols are supported via LIMS!
LIM for HiPath 33x0 and HiPath 35x0 can be used for CTI/CSTA applications in conjunction
with TAPI 120 (up to 6 stations). No other features or protocols are supported via LIM!
Topic
HiPath 3800 HiPath 3550
HiPath 3500
HiPath 3350
HiPath 3300
Feature available in xxx
Hardware requirements HG 1500 HG 1500 / LIM
Software requirements V5.0 or later V1.2 or later V1.2 or later
