wclient.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

10-89

Nur für den internen Gebrauch Workpoint Clients

optiPoint 500

10.5.1.6 Connection Requirements for HiPath 3000

Hardware requirements

Connecting as a client telephone

System HiPath 3800 HiPath 3550

HiPath 3500

HiPath 3350

HiPath 3300

Hardware require-

ments

free U

P0/E

port on

SLMO2/8

free U

P0/E

port on

CBCC

CBRC

SLU8

SLU8R

SLMO24

free U

P0/E

port on

CBCC

CBRC

SLU8

SLU8R

The device can also be connected to an existing optiPoint 500 telephone (except for

optiPoint 500 entry and optiPoint 500 economy) as a client telephone (using an op-

tiPoint phone adapter).
