Siemens HiPath 3000 Series - Supplying the System with Power

Starting Up HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
5-12 HiPath 3000/5000 V9, Service documentation
start_h3.fm
Starting Up HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300
5.2.2 Supplying the System With Power
Procedure
RUN LED HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300
The central board has a RUN LED that indicates the system status.
7
Caution (for Brazil only)
The use of the outlet strip with overvoltage protection with part number C39334-
Z7052-C33 is absolutely mandatory. The AC power of the system must be conduct-
ed through the outlet strip with overvoltage protection.
Step Activity
1. Plug in the power supply cable and, where applicable, the battery cable.
Note (for Brazil only): The AC power of the HiPath 3550, HiPath 3350, HiPath
3500, and HiPath 3300 systems is internally equipped with transient overvoltage
protection up to approx. 2 kV. Since additional lightning protection is prescribed
for Brazil, the AC power of a system must be conducted through the outlet strip
with overvoltage protection (part number C39334-Z7052-C33). In this way, tran-
sient overvoltage protection is guaranteed up to approx. 4 kV.
2. Monitor the Run LED of the central controller. The individual steps of the system
boot (Table 5-6) can be observed this way.
Table 5-6 RUN LED - LED Status Meaning
RUN LED Meaning
Off No power
On Reset switch pressed briefly
Off Reset switch held down for more than 5 seconds (LED is extinguished
to acknowledge that a reload has begun)
On System boot
Off
for 0.1 s
Load operation: APS in SDRAM, loadware, and card data
Flashing
0.5 s on/0.5 s off
Normal operating state (zero load)
1
1 The flashing rhythm depends on the load. The higher the system load the slower the flashing rhythm.
Flashing
0.1 s on/0.1 s off
MMC removed or defective
