OpenStage Product Family

10.1.2.3 OpenStage 20

Product image

Versions

The following telephones are available for the CorNet IP (HFA) connection variant:

● OpenStage 20 E (without full-duplex speakerphone mode)

● OpenStage 20

● OpenStage 20 G (gigabit variant)

Main features

Figure 10-3 OpenStage 20

Feature Connection variant

CorNet-IP (HFA) TDM

General fea-

tures

Tilt LCD graphics display, 24 x 2 character resolution, monochrome

multi-functional 3-way navigator

General fea-

tures

7 pre-programmed function keys: Disconnect, call forwarding, redial, service/

application menu, voice messages, loudspeaker, mute

Full-duplex speakerphone mode (not for 20 E)
