4.1.7.3 Inserting External S

Patch Panel C39104-Z7001-B3

Structure

All incoming cables must be attached to the patch panel using cable ties.

Figure 4-43 S

Patch Panel C39104-Z7001-B3

3 x 8 MW8 jacks

Necessary height units for 19-inch cabinet assembly: 1

(one height unit corresponds to approx. 1.7’’=43 mm)
