Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-366 HiPath 3000/5000 V9, Service documentation
boards.fm
Options
3.4.5 Announcement and Music Modules
Introduction
The HiPath 3000 systems use different modules or boards for playing announcements and mu-
sic on hold. For details on connecting these boards, refer to the manufacturer’s installation in-
structions.
Overview of Boards
7
Caution
Place the central control board on a flat surface before inserting a subboard. Other-
wise you may damage the board.
>
The following HiPath Xpressions Compact boards support music on hold in V4.0
SMR-7 or later and announcements in V5.0 or later:
● IVMNL, IVMN8 (HiPath 3800)
● IVMP8 (not for U.S.) and IVMP8R (not for U.S.) (HiPath 3350, HiPath 3300)
● IVMS8, IVMS8R (HiPath 3550, HiPath 3350, HiPath 3500, HiPath 3300)
For detailed information on HiPath Xpressions Compact, startup and administration,
see the manual for the product.
Table 3-179 Announcement and Music Modules
Module / Board Part number Use
EXM S30817-Q902-B401
● Used in HiPath 3550 and HiPath 3350 (wall hous-
ing), see Figure 3-132.
● Connected via cable to X4 connector on CBCC/
CBCP.
EXMNA (for U.S. only) S30807-Q6923-X
● Implemented in HiPath 3550, HiPath 3350 (wall
housing), see Section 3.4.7.
EXMR S30122-K7403-Z
S30122-K7403-T
● Implemented in HiPath 3550, HiPath 3350 (wall
housing), and HiPath 3500, HiPath 3300 (19”
housing).
● Module installed directly on CBCC/CBRC (X19
and X20).
● Wall housing: Direct connection to external music
source (see Figure 3-133).
● 19” housing: Connected via cable to cinch jack on
the front panel (see Figure 3-134).
