Nur für den internen Gebrauch Boards for HiPath 3000

Options

Contact assignment

Table 3-178 ANI4R (for selected countries only) - Contact Assignment

X3 Pin Signal X3 Pin Signal

1 – 6 a-wire (tip), trunk 3

2 a-wire (tip), trunk 1 7 b-wire (ring), trunk 3

3 b-wire (ring), trunk 1 8 a-wire (tip), trunk 4

4 a-wire (tip), trunk 2 9 b-wire (ring), trunk 4

5 b-wire (ring), trunk 2 10 Call charging module assignment

(GMZ)
