Siemens HiPath 3000 Series - CUC and CUCR

Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-44 HiPath 3000/5000 V9, Service documentation
boards.fm
Central Board
3.2.6 CUC and CUCR
The backplane comes in two versions:
● CUC (Connection Unit Com) S30777-Q750-X (Figure 3-9) - for use in HiPath 3550 (wall
housing)
● CUCR (Connection Unit Com Rack) S30777-Q750-Z (Figure 3-10) - for use in HiPath 3500
(19-inch housing)
CUC connector designations and slot assignments (S30777-Q750-X)
CUCR connector designations and slot assignments (S30777-Q750-Z)
Figure 3-9 CUC Backplane (S30777-Q750-X)
Figure 3-10 CUCR Backplane (S30777-Q750-Z)
Slot 6 (X40)
Slot 8 (X60)
Slot 4 (X20)
Slot 7 (X50)
Slot 9 (X70)
Slot 5 (X30)PSU/UPS (X1)
Slot 2 (8 x U
P0/E
) Slot 1 (2 x S
0
) Slot 3 (4 x T/R)
CUC
Peripheral board
CBCC
Peripheral board
Peripheral board
Slot 10
For SLMO24, SLA24N or
SLC16N
Slot 6 (X40)
Slot 8 (X60)
Slot 4 (X20)
Slot 7 (X50)
Slot 9 (X70)
Slot 5 (X30)PSU/UPS (X1)
Slot 2 (8 x U
P0/E
) Slot 1 (2 x S
0
) Slot 3 (4 x T/R)
CUCR
Peripheral board
CBRC
Peripheral board
Peripheral board
