Siemens HiPath 3000 Series - Using an External Main Distribution Frame MDFU-E S30805-U5283-X

To Next Page

To Previous Page

inst_h3.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

4-67

Nur für den internen Gebrauch Installing HiPath 3000

Installing HiPath 3800

4.1.7.1 Using an External Main Distribution Frame MDFU-E S30805-U5283-X

For U.S. only:

No more than 21 CABLUs per MDFU-E with one 16-TW strip or 25-TW strip (9 x 30 mm) can

be implemented.

Figure 4-36 MDFU-E - Layout and Dimensions (669.0 x 328.8 x 125.4 mm)

System side Line network

Jumpering

Channel

21 slots (9 x 30 mm)

328.8 mm

669.0 mm

Special built-in

comps.

2 x PFT1

Main Page

Default Chapter3
