OpenStage Product Family

10.1.2.5 OpenStage 40

Product image

Versions

The following telephones are available for the CorNet IP (HFA) connection variant:

● OpenStage 40

● OpenStage 40 G (gigabit variant)

Main features

Figure 10-5 OpenStage 40

Feature Connection variant

CorNet-IP (HFA) TDM

General fea-

tures

Tilt LCD graphics display with background lighting, 40 x 6 character resolu-

tion, monochrome
