OpenStage Product Family
10.1.4 Powering the OpenStage Telephones, Add-On Devices, and
Adapters
The following tables provide information on the configurations at which a power supply is re-
quired using an external power supply. For the additional power supply, use only the associat-
ed original power supply (see Section 10.1.5.1, “External Power Supply”).
CorNet-IP connection variants
Telephone Configuration Additional pow-
er supply re-
quired?
Note
OpenStage 20 – No
1
OpenStage 20
Gigabit variant
– No
2
OpenStage 40 – No
2
1 x OpenStage
Key Module 15
No
2
1 x OpenStage
Key Module 40
No
2
2 x OpenStage
Key Module 40
No
2
1 x OpenStage BLF Yes, for Open-
Stage BLF
● OpenStage BLF up to and in-
cluding hardware output
S30817- S7406-A101-7/-A103-
2: The external power supply
unit is connected to the BLF.
Caution: The power supply unit
used should only be used for
this purpose. Using the free
jack of the power supply unit to
power another terminal or de-
vice is not permitted and can
lead to the destruction of the
OpenStage BLF.
● OpenStage BLF, hardware re-
lease S30817-S7406-A101-8/
- A103-3 or higher: The external
power supply unit is connected
to the terminal (see Figure 10-
18).
