Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-16 HiPath 3000/5000 V9, Service documentation

wclient.fm

OpenStage Product Family

10.1.2.6 OpenStage 60

Product image

Versions

The following telephones are available for the CorNet IP (HFA) connection variant:

● OpenStage 60

● OpenStage 60 G (gigabit variant)

Main features

Figure 10-6 OpenStage 60

Feature Description

Display TFT, swivel, background lighting, 320 x 240 pixels, QVGA, 16 bit color

depth, suitable for graphics

Pre-programmed func-

tion keys, left

● End call (disconnect)

● Switch call forwarding on/off

● Switch voice dialing on/off
