Siemens HiPath 3000 Series

To Next Page

To Previous Page

wclient.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

10-19

Nur für den internen Gebrauch Workpoint Clients

OpenStage Product Family

10.1.2.7 OpenStage 80

Product image

Versions

The following telephones are available for the CorNet IP (HFA) connection variant:

● OpenStage 80

● OpenStage 80 G (gigabit variant)

Main features

Figure 10-7 OpenStage 80 [CorNet-IP (HFA)]

Feature Description

Display TFT, swivel, background lighting

● TDM: 320 x 240 pixels, QVGA, 16 bit color depth, suitable for

graphics

● CorNet-IP (HFA): 640 x 480 pixels, VGA, 16 bit color depth, suit-

able for graphics
