4.1.7.2 Inserting the External Patch Panel S30807K6143-X

Structure

All incoming cables must be attached to the patch panel using cable ties.

Figure 4-39 Patch Panel S30807-K6143-X

MW8 jack assignment:

4 = a-wire

5 = b-wire

Necessary height units for 19-inch cabinet assembly: 1

(one height unit corresponds to approx. 1.7’’=43 mm)

SIVAPAC edge connector: port for

CABLU connection to the backplane

Eight surge protector plug loca-

tions

Front panel with 3 x 16 MW8 jacks
