Siemens HiPath 3000 Series - Hipath 3550 Board Power Requirement

Identifying System Power Requirements Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
D-4 HiPath 3000/5000 V9, Service documentation
power_calc.fm
HiPath 3550 Board Power Requirement
D.2 HiPath 3550 Board Power Requirement
Table D-3 Nominal Output of the HiPath 3550 Power Supply Units
Power Supply Unit Part Number Max. Nominal Output in W
5 V –48 V
UPSC-D S30122-K5660-A300
S30122-K5660-M300
40.0 53.0
Powerbox PB3000 with
LUNA2
S30177-U773-X with
S30122-K7686-M1
– 110
>
You must check whether the total power requirement of the boards used and the
workpoint clients connected exceeds the maximum possible output of the UPSC-D
with or without Powerbox PB3000. Section D.7 contains a sample calculation.
Table D-4 HiPath 3550 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
BS3/1 S30807-H5482-X – 2.0
BS3/3 S30807-H5485-X – 3.0
CBCC (including sub-
boards)
S30810-Q2935-A301 7.0 0.5
GEE12 S30817-Q951-Axxx 0.5 –
GEE16 S30817-Q951-Axxx 0.5 –
GEE50 S30817-Q951-Axxx 0.5 –
HXGS3 (including venti-
lator kit)
S30810-Q2943-X, S30810-Q2943-X1 10.0 2.8
HXGS3 (excluding ven-
tilator kit)
S30810-Q2943-X, S30810-Q2943-X1 10.0 –
IVMS8 S30122-Q7379-X 2.6 0.3
P DM1 S30807-Q5692-X100 – 5.0
SLA8N S30810-Q2929-X200 0.2 0.5
SLA16N S30810-Q2929-X100 3.0 3.0
SLA24N S30810-Q2929-X 4.5 4.5
SLAD4 S30810-H2956-X100 2.0 1.0
