power_calc.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

D-5

Nur für den internen Gebrauch Identifying System Power Requirements

HiPath 3550 Board Power Requirement

SLAD8 S30810-H2956-X200 2.0 1.0

SLAD16

S30810-Q2957-X 2.5 1.5

SLC16N S30810-Q2193-X100 5.0 –

SLMO24 S30810-Q2901-X 1.5 –

SLU8 S30817-Q922-A301 0.8 –

STLS2 S30817-Q924-B313 0.6 –

STLS4 S30817-Q924-A313 1.0 –

STRB S30817-Q932-A 0.5 –

T CAS-2 S30810-Q2945-X 4.5 –

TLA2 S30817-Q923-Bxxx 0.1 –

TLA4 S30817-Q923-Axxx 0.2 –

TLA8 S30817-Q926-Axxx 0.4 –

TMAMF S30810-Q2587-A400 1.8

16.9

TMCAS S30810-Q2938-X Information not available

TMGL4 S30810-Q2918-X 4.7

0.1

TMQ4 S30810-Q2917-X 3.8 –

TST1 S30810-Q2919-X 0.8 –

TS2N S30810-Q2913-X300 0.9 –

V24/1 S30807-Q6916-X100 0.3 –

4SLA S30810-Q2923-X200 0.7 0.7

8SLA S30810-Q2923-X100 1.3 1.3

16SLA S30810-Q2923-X 2.5 2.5

1 Detailed configuration rules are provided in section 3.3.12 SLAD16.

2 For each active (off hook) station, the net resource requirement increases by approximately 1.6W (dependent on the tele-

phone’s line length and DC resistance).

3 Identified at a traffic flow of 0.8 Erlang

Table D-4 HiPath 3550 Board Power Requirement

Board or Component Part Number Net Power Requirement in

5 V –48 V
