Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Extension modules

The HXGS3 and HXGR3 boards each have two HGA (HiPath Gateway Accelerator) slots,

which can be used to connect extension modules.

Table 3-39 HXGS3/HXGR3 - Extension Modules

Extension module Part number Function Notes

PDM1

(PMC DSP mod-

ules)

S30807-

Q5692-X100

Used for expansion for an addition-

al eight DSP channels.

Maximum of one

PDM1 module pos-

sible.

Figure 3-34 HXGS3 (S30810-Q2943-X, S30810-Q2943-X1)

Figure 3-35 HXGR3 (S30810-K2943-Z)
