Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-96 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
Upgrade, fan kit
If the following housing covers are available on the HiPath 3350 and HiPath 3550 systems, a
fan kit is not required when upgrading with a HXGS3:
● HiPath 3350: from housing cover C39165-A7021-B53
● HiPath 3550: from housing cover C39165-A7021-B52
Board versions
Eight simultaneous Voice over IP connections are possible per DSP (Digital Signal Processor).
>
If the HiPath 3350 and HiPath 3550 systems have the old housing covers and should
be upgraded with a HXGS3, then the old housing covers must be replaced by
C39165-A7021-B53 or C39165-A7021-B52 housing covers.
Table 3-38 HXGS3/HXGR3 Board Versions
Board Part number Services DSPs B channels
DSP chan-
nels
HXGS3 S30810-Q2943-X Voice and Data 1 8
HXGS3; with new software for
HiPath 3000 V8
S30810-Q2943-X1 Voice and Data 1 8
HXGS3; for HiPath 3500, 3300
(S30810-Q2943-X1 + panel)
S30810-K2943-Z1 Voice and Data 1 8
HXGR3 S30810-K2943-Z Voice and Data 1 8
>
When using the extension module PDM1, the number of DSP channels for HXGS3
and HXGR3 boards can be expanded by eight per board.
