wclient.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
10-33
Nur für den internen Gebrauch Workpoint Clients
OpenStage Product Family
OpenStage 40
Gigabit variant
– No
3
1 x OpenStage
Key Module 15
No
3
1 x OpenStage
Key Module 40
No
3
2 x OpenStage
Key Module 40
No
3
1 x OpenStage BLF Yes, for Open-
Stage BLF
● OpenStage BLF up to and in-
cluding hardware output
S30817- S7406-A101-7/-A103-
2: The external power supply
unit is connected to the BLF.
Caution: The power supply unit
used should only be used for
this purpose. Using the free
jack of the power supply unit to
power another terminal or de-
vice is not permitted and can
lead to the destruction of the
OpenStage BLF.
● OpenStage BLF, hardware re-
lease S30817-S7406-A101-8/
- A103-3 or higher: The external
power supply unit is connected
to the terminal (see Figure 10-
18).
OpenStage 60 – No
3
1 x OpenStage
Key Module 60
No
3
2 x OpenStage
Key Module 60
No
3
OpenStage 60
Gigabit variant
– No
3
1 x OpenStage
Key Module 60
No
3
2 x OpenStage
Key Module 60
Yes The external power supply unit is
connected to the terminal
(see Figure 10-18)
Telephone Configuration Additional pow-
er supply re-
quired?
Note
