Installing HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
4-122 HiPath 3000/5000 V9, Service documentation
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
Static Traffic Capacity
The HiPath 3500 and HiPath 3300 systems have the following static traffic capacities.
Table 4-14 HiPath 3500 and HiPath 3300 - Static Traffic Capacity
System Slots Static traffic capac-
ity
Total static traffic capacity
of the system
HiPath 3500
(see Figure 4-66)
2/3 (CBRC) 24 erlangs
134 erlangs
4 16 erlangs
5 16 erlangs
6 16 erlangs
7 16 erlangs
8 16 erlangs
9 30 erlangs
1
1 Use of a TS2R board results in a capacity of 30 erlangs. A maximum of one TS2R per HiPath 3500 is possible, and the
board may only be installed in slot 7 or 9, thus resulting in 30 Erlangs for slot 7 or 9.
HiPath 3300
(see Figure 4-67)
2/3 (CBRC) 24 erlangs
56 erlangs4 16 erlangs
5 16 erlangs
