Nur für den internen Gebrauch Starting HiPath 3000 as a Gateway
Starting HiPath 3800 as a Gateway
9. Making Trunk Connections
Refer to the following board descriptions for information:
● STMD3 - for S
0
trunk connection
● DIUN2 - for S
2M
trunk connection
● DIU2U (for U.S. only) - for T1 PRI trunk
● DIUT2 - for the S
2M
trunk connection and the T1 trunk connection (PRI or an-
alog)
10. Making IP connections
Perform the IP connection over the HG 1500 board, STMI2.
For information on configuration, refer to the HG 1500 Administration Manual.
11. Performing a Visual Inspection, page 4-83
Startup of HiPath 3800 (Section 5.1)
1. Supplying the System with Power, page 5-2
(Plugging in the system cabinet(s) -> starting system boot)
Note (for Brazil only): The AC power of a system cabinet is internally equipped with
transient overvoltage protection up to approx. 2kV. Since additional lightning pro-
tection is prescribed for Brazil, the AC power of the system cabinet(s) must be con-
ducted through the outlet strip with overvoltage protection (part number C39334-
Z7052-C33). In this way, transient overvoltage protection is guaranteed up to ap-
prox. 4 kV.
2. Carrying Out a System Reload, page 5-6
3. Carrying Out the Country Initialization and Selecting the Password Type, page 5-7
4. Not for U.S.: Entering the System Number, page 5-9
5. Conducting customer-specific programming with HiPath 3000/5000 Manager E.
Refer to the HiPath 3000/5000 Manager E Help for information on programming in-
dividual features.
Table 7-1 HiPath 3800 as a GW, Procedure for System Installation and Startup
Step Activity (Remarks)
To Next Page
