Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-344 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
with each ECG cabinet, for information on the connection and power supply.
For HiPath 3000 V1.0 and later, you can also use the new TMCAS board to support country-
specific CAS protocols.
TS2N interfaces (old: TS2)
TS2R interfaces
Figure 3-118 TS2N (not for U.S.) - Interfaces (S30810-Q2913-X100, -X300)
Figure 3-119 TS2R (not for U.S.) - Interfaces (S30810-K2913-Z100, -Z300)
X1
50
2
X2
8
1
To CUC
TS2N
S
2M
interface:
● Wieland termi-
nal (symm. line)
X5
1
● MW8 (RJ48C)
jack (MW line)
X1
50
2
To CUCR
TS2R
X5
1
S
2M
interface:
● MW8 (RJ48C)
jack (MW line)
