HiPath 3000/5000 in the LAN Network Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
13-52 HiPath 3000/5000 V9, Service documentation
h3h5_in_the_lan.fm
HG 1500 Board
The “vs.” column shows the relationship between the DiffServ and IP precedence standards.
Since DiffServ offers more variants, the codepoint is permanently selected when translating IP
precedence into DiffServ: for example, the codepoint for the IP precedence “100”, for example,
becomes “AF31”. In the case of packet that leave HG 1500 in the direction of the LAN, the user
priority specified in the last column is set when IEEE 802.1p is active.
QoS can be activated for the second LAN interface as well as for the ISDN partner. For this
interface, the interface is extended by an additional transmission rate limitation. The function
of the quality evaluation corresponds to the ISDN peer procedure. The average transmission
rate is set in configuration data.
AF 42 100100 90 x <-> 011 60 011
AF 43 100110 98 x <-> 011 60 011
EF 101110 B8 <-> 110 C0 110
DE
(default)
000000 00 000
001
010
00
20
40
000
Table 13-4 Codepoint Implementation
IP header Ethernet
header
DiffServ vs. IP Precedence IEEE802.1p
Code-
point
Default (can be
changed)
Drop level Assignment
(fixed)
Binary
(bit field)
ToS
field
(hex)
high med low Binary
(bit field)
ToS
field
(hex)
User Priority
(binary, bit
field)
