Dynamic Configuration Rules
With a permissible maximum points total of 980, this scenario is feasible.
Bandwidth calculation:
A 2Mbit/s connection is sufficient for the customer.
Table 2-56 Performance Calculation (2)
Function Formula Points
Signaling: IP phones (without H.235) 4 · 3.2 13
Gateway channels: G.729 with VPN and AES 4 · 89 356
Data (LAN): VPN and AES with 500 bytes upstream 250 · 1.19 298
Data (LAN): VPN and AES with 500 bytes downstream 250 · 1.19 298
Total 965
Table 2-57 Bandwidth Calculation
Function Formula Points
Voice channels: G.729 with VPN and AES 4 · 60 240
Data (LAN): VPN and AES with 500 bytes 1000 1000
Total 1240
