System Programming Codes (Expert Mode Codes) Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

A-26 HiPath 3000/5000 V9, Service documentation

pcodes.fm

Accessing system administration

29 5 2 00

Select country code

11 = Germany

12 = Netherlands

13 = France

14 = Finland

15 = United Kingdom

16 = Italy

17 = Spain

18 = Portugal

19 = Switzerland

20 = Austria

21 = International

22 = Ireland

23 = Belgium

24 = Brazil

25 = South Africa

26 = China

28 = India

29 = Czech Republic

30 = Denmark

31 = Australia

32 = Argentina

33 = Philippines

35 = Brazil 2

36 = Singapore

37 = Hungary

38 = Malaysia

40 = Indonesia

41 = Russia

42 = Thailand

46 = Poland

47 = Greece

49 = Sweden

50 = Norway

51 = Turkey

52 = U.S.

53 = Pakistan

54 = Hong Kong

55 = New Zealand

56 = Taiwan

57 = Korea

29 6 Virtual subscribers
