Product Specific Attributes

HiPath 5000 V7

Issue: 18

April 2007 Page - 7 -

Siemens Enterprise Communications GmbH & Co KG

Application Function Type A-Prot.

M-

Prot.

T-Prot.

D-

Ports

A-

Ports

Remarks

SIP Call Signalling active

(TCP) Call Signalling for

SIP endpoints and SIP

based trunking

client SIP --- TCP

1024 -

65535

Def: Ephemeral Ports (IANA)

SIP Call Signalling passive

Call Signalling for SIP

endpoints and SIP based

trunking

server SIP --- TCP_UDP 5060

1 -

65535

Def: SIP

Adm: Default can be modified within

this range
