Product Specific Attributes
HiPath 5000 V7
Issue: 18
th
April 2007 Page - 12 -
Siemens Enterprise Communications GmbH & Co KG
2.1.2.3 optiPoint 410/420 V5 R3
Application Function Type A-Prot.
M-
Prot.
T-
Prot.
D-
Ports
A-
Ports
Remarks
H.323 (oP410) General term for H.323 functions
.
H.323 Call Signaling
(oP410)
active Voice over IP
client
H.323
(H.225-
Q.931)
--- TCP
1024 -
65535
Def: Ephemeral Ports (IANA)
.
H.323 Call Signaling
(oP410)
passive Voice over IP
server
H.323
(H.225-
Q.931)
--- TCP 1720
0 -
65535
Def: H.225/Q.931
.
H.323 Payload Transport
(oP4x0 at H2k/H3k)
active Voice over IP
client RTP_RTCP --- UDP
5004 -
5013
0 -
65534
Def: RTP portnumber is negotiated via
H.245. Max 5 connections: RTP starts at
<adr> port2/max - 1 down to <adr> port
1/min , RTCP at <adr> port2/max down to
<adr> port 1/min+1
Adm: even port number only
.
H.323 Payload Transport
(oP4x0 at H2k/H3k)
passive Voice over IP
server RTP_RTCP --- UDP
5004 -
5013
0 -
65534
Def: RTP portnumber is negotiated via
H.245. Max 5 connections: RTP starts at
<adr>, RTCP at <adr>+1 (=RTP+1).
Adm: even port number only
.
H.323 Payload Transport
(oP4x0 at H4k)
active Voice over IP
client RTP_RTCP --- UDP
5008 -
5013
0 -
65534
Def: Attention: The phone is prepared to
handle up to 5 port couples in total. If the
base port is set to 5004 inside the phone,
the port range then is 5004 ... 5013. But, in
H4k scenarios, only the upper three couples
(starting from the top) are used: 5012/5013,
5010/5011 and 5008/5009 .
Adm: even port number only
.
H.323 Payload Transport
(oP4x0 at H4k)
passive Voice over IP
server RTP_RTCP --- UDP
5008 -
5013
0 -
65534
Def: Attention: The phone is prepared to
handle up to 5 port couples in total. If the
base port is set to 5004 inside the phone,
the port range then is 5004 ... 5013. But, in
H4k scenarios, only the upper three couples
(starting from the top) are used: 5012/5013,
5010/5011 and 5008/5009 .
Adm: even port number only
HFA (oP410) Hicom Feature Access
.
CorNet TC Logon
(oP600) CorNet TC
Logon Port
client *proprietary* --- TCP 4060 Def: CorNet-TC
OAM (oP410 HFA) Administration of optiPoint HFA devices
.
DLS Workpoint Interface
(client sided) workpoint
sided DLS
Communication interface
workpoints
client WPIP HTTPS TCP 18443
0 -
65535
Def: DLS: Communication interface
workpoints – DLS
.
FTP_Server_Control
(oP410) FTP-Server
server FTP --- TCP 21 Def: FTP-Server Control Port
.
HTTPS_Server (Phones)
Secure Embedded Web
Server
server HTTP --- TCP 443
0 -
65535
Def: HTTPS
.
HTTP_Server (Phones)
Web Interface
server TFTP --- TCP 8085
0 -
65535
Def: HTTP optiPoints, HG1500
.
IP-Config (Phones) IP
Configuration Services
server *proprietary* --- UDP 5100
.
SNMP (SET/GET)
(Phones) SNMP
SET/GET-Functionality
server SNMP --- UDP 161 Def: SNMP (Set/Get)
.
SNMP Trap (oP410)
SNMP Trap function
client SNMP --- UDP
161
162
Def: SNMP Trap (oP410)
