Product Specific Attributes
HiPath HG 1500 V7
Issue: 18
th
April 2007 Page - 12 -
Siemens Enterprise Communications GmbH & Co KG
Application Function Type A-Prot.
M-
Prot.
T-
Prot.
D-
Ports
A-
Ports
Remarks
.
SIP Payload
Transport (oP410)
passive Voice over
IP: Transmission of
Payload
server RTP_RTCP --- UDP
5004 -
5027
0 -
65534
Def: Port 5004 .. 5006 for normal usage.
For every line-key you have to add two
channels. The maximum of line keys are
10 -->. For this the maximum range of
5004 .. 5027 is valid
Adm: even port number only
SIP Signalling (op410 SIP) Session Inition Protocol (SIP) signaling
.
SIP Signaling (WL2-
Phone) SIP over TLS
client SIP ---
TCP -
TLS
5061 Def: SIP
.
SIP signaling TCP
(oP410) SIP
signalling in the case
of using TCP
(configurable inside
the phone)
client SIP --- TCP 5060 Def: SIP
.
SIP signaling UDP
(oP410) SIP
signalling in the case
of using UDP
(configurable inside
the phone)
client SIP --- UDP 5060 Def: SIP
.
SIP-TLS (OP410)
SIP over TLS
client SIP ---
TCP -
TLS
5061
1 -
65535
Def: SIP
Adm: Configuration the port value to
zero will result in the default port value
being used
User Applications (oP410 SIP) bundle of user functions
.
JAVA (optiPoints)
JAVA applications in
phones
client HTTP --- TCP 9200
0 -
65535
Def: Java default port in optiPoint
phones
.
LDAP Access
(optiPoint phones)
Directory access via
LDAP
client LDAP --- TCP 389
0 -
65535
Def: LDAP
.
WAP client (TCP) for
WAP access to WAP
services (server)
client WAP --- TCP 9200
0 -
65535
Def: WAP connectionless session
service (IANA)
