Product Specific Attributes

HiPath HG 1500 V7

Issue: 18

April 2007 Page - 16 -

Siemens Enterprise Communications GmbH & Co KG

Application Function Type A-Prot.

M-

Prot.

T-

Prot.

D-

Ports

A-

Ports

Remarks

QoS Data Collection Unit (QCU) phones Send QoS reports,

QCU client 12010

Client application

which sends QDC data

to the QCU

client SNMP --- UDP 12010

0 -

65535

Def: QCU receiving Port
