Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-28 HiPath 3000/5000 V9, Service documentation
boards.fm
Central Board
Switches and indicators
● Reset/reload switch
– Switch pressed < 5 s = Reset activated
– Switch pressed > 5 s = Reload activated (RUN LED out indicates that a reload is in
progress)
● Run LED
LED status meaning is explained in the following table.
Table 3-10 CBRC - LED Status Meaning
RUN LED Meaning
Off No power
On Reset switch pressed briefly
Off Reset switch held down for more than 5 seconds (LED is extin-
guished to acknowledge that a reload has begun)
at System boot
Off
for 0.1 s
Load operation: APS in SDRAM, loadware, and card data
Flashing
0.5 s on/0.5 s off
Normal operating state (zero load)
1
1 The flashing rhythm depends on the load. The higher the system load the slower the flashing rhythm.
Flashing
0.1 s on/0.1 s off
MMC removed or defective
