Central Board
Figure CBRC S30810-Q2935-Z301
Figure 3-4 CBRC Board (S30810-Q2935-Z301)
>
Disconnecting the battery buffer by unplugging the X27 jumper is necessary only for
testing (module test at the factory). Disconnection does not necessarily delete the
customer database (CDB). To delete the CDB, use the reset switch.
2
X27
X5
2
X11 X6
X8 O bus
X14
CMA
X13
CMS
X17
IMODN
X15 X16
X12
LIM
EVM
X32
X18
2
X3
X20
X19
MMC
4 x T/RReset/Reload
keys
RUN LED
LAN connector, 8-pin RJ45 jack
V.24 interface, 9-pin
SUB-D plug
2 x S
0
,
RJ45
jacks
X9
1
X1
8 x U
P0/E
1
MPPI,
MUSIC
or
EXMR
sub-
board
