Siemens HiPath 3000 Series

To Next Page

To Previous Page

boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-39

Nur für den internen Gebrauch Boards for HiPath 3000

Central Board

V.24 interface assignment

LAN connector assignment via LIMS

Table 3-17 CBSAP - V.24 Interface Assignment (SUB-D Plug)

X50/X51, Pin Signal Description

1 DCD Data carrier detect (not used)

2 RxD Receive data

3 TxD Transmit data

4 DTR Data terminal ready (not used)

5 0 V Ground

6 DSR Data send ready (not used)

7 RTS Request to send

8 CTS Clear to send

9 RI Ring indicator (not used)

Table 3-18 CBSAP - LAN Connector Assignment (RJ45 Jack)

Pin Signal Description

1 Tx + Transmit +

2 Tx – Transmit –

3Rx+Receive+

4 – Not used

5 – Not used

6Rx–Receive–

7 – Not used

8 – Not used
