Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-54 HiPath 3000/5000 V9, Service documentation

boards.fm

Central Board

RJ45 jack assignment

Figure 3-15 CBSAP with LIMS Module Plugged In

Table 3-21 LIMS - RJ45 Jack Assignment

Pin Signal Description

1 Tx + Transmit +

2 Tx – Transmit –

3Rx+Receive+

4 – Not used

5 – Not used

6Rx–Receive–

7 – Not used

8 – Not used
