Central Board
Approved battery packs for UPSC-D
The following battery packs have been approved and released for operation with the UPSC-D
board:
● 48 V battery pack S30122-K5928-X (4 x 12 V/1.2 Ah)
● 48 V battery pack 4 x V39113-W5123-E891 (4 x 12 V/7 Ah)
● Not approved: The 24 V-battery pack S30122-K5403-X is not approved.
Technical Specifications
● Nominal voltage range: 100 VAC - 240 VAC
● Nominal frequency: 50 Hz - 60 Hz
● Ring voltage generator 75 Vac, 20/25/50 Hz
● Partial voltages: +5 VDC, -48 V
● Battery charger: 4 x 12 V (40,8 V-55,2 V)
● Power consumption: 180 W
● Bridging times: See next paragraph.
Bridging times
The maximum possible bridging times of the HiPath 3350 and HiPath 3550 systems in emer-
gency battery mode can be found here, i.e., if the power supply has failed. A distinction is made
between a 48 V/1.2 Ah battery pack and the Power Box with 48 V/7 Ah (without LUNA2). The
bridging times are determined under the following conditions:
● All measurements were performed at a room temperature of approximately 23 °C (73.4
°F).
7
CAUTION
Risk of explosion as a result of the 24 V battery pack (S30122-K5403-X) at
the UPSC-D
Connecting the 24 V battery pack (S30122-K5403-X) to the UPSC-D is prohib-
ited. The battery pack overcharges during operation and emits explosive gas
(hydrogen + oxygen).
>
NOTE
The UPSC-D does not charge a battery pack that has less than 35 V (tolerance:
33 V to 37 V). This ensures that operating a low-voltage battery pack, e.g., a 24
V battery pack, or a faulty battery pack is not possible at the UPSC-D.
