boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-71
Nur für den internen Gebrauch Boards for HiPath 3000
Central Board
Diagram of UPSC-D
Figure 3-22 UPSC-D (S30122-K5660-M300)
Figure 3-23 UPSC-D (S30122-K5660-A300/-M300)
LED, yellow
X1
to
CUC/
CUP
1
50
Slide switch for setting the ring frequen-
cy
Slide switch for activating/deactivating
the battery voltage (battery pack):
● up = off, battery voltage deactivated
(battery backup off)
● down = on, battery voltage activated
(battery backup on)
25 Hz
20 Hz
50 Hz
B
a
t
t
e
r
y
p
a
ck
P
B
30
0
0
P
o
we
r
p
l
u
g
LED, yellow
LED,
green
