Siemens HiPath 3000 Series

To Next Page

To Previous Page

boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-73

Nur für den internen Gebrauch Boards for HiPath 3000

Central Board

Connectors

Figure 3-25 UPSC-D - Connectors

Power plug

Port for external power supply unit (in

PB3000)

Port for battery pack or batteries (in PB3000)
