Peripheral boards
Front panel
An additional shielding panel is not required on the front side of this board, because the EMC
shield is already provided by the front panel.
15 41 a-wire (T), receive wht/ora
8 16 b-wire (R), receive ora/wht
Figure 3-31 DIU2U (for U.S. only) - Front Panel (S30810-Q2216-X)
Table 3-29 DIU2U (for U.S. only) - adapter cable assignment (C39195-A7269-B625)
15-pin Sub-D
connector
Pin
50-pin Amphenol con-
nector
Pin
Function Color code
Two LEDs indicating the board status:
● LED (green)
● LED (red)
Interface 2
Interface 1
