Peripheral boards
Jack assignment
Assigning the system cable S30267-Z167-Axxx
Table 3-32 DIUN2 - 15-Pin Sub-D Jack Assignment
Pin Signal Signal description Direction
1 TTIP0 a-wire 120 ohms/75 ohms Output
4 LWLO0_FRONT Fiber optic (data output) Output
5 GND Ground return path for the +5-V
power supply
Input/output
6 SCAN_IN0 Adapter test Input
7 SCAN_IN0 Adapter test Input
8 RTIP0 a-wire 120 ohms/75 ohms Input
9 TRING0 b-wire 120 ohms/75 ohms Output
10 +5 V +5-V power supply Output
11 LWLI0_FRONT Fibre optic (data input) Input
12 GND Ground return path for the +5-V
power supply
Input/output
14 +5 V +5-V power supply Output
15 RRING0 b-wire 120 ohms/75 ohms Input
No other pins used.
Table 3-33 DIUN2 - Assignment of System Cable S30267-Z167-Axxx
Pin Function Color code
8 a-wire (T), transmit ora/wht
15 b-wire (R), transmit wht/ora
1 a-wire (T), receive blu/wht
9 b-wire (R), receive wht/blu
