Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-112 HiPath 3000/5000 V9, Service documentation

boards.fm

Peripheral boards

Assignment of the RJ45 jack X3

The Ethernet (10/100BaseT) interface is accessed via the 8-pin RJ45 jack X3. The signals are

output simultaneously at the printed circuit connector X2.

Table 3-46 IVMP8 and IVMP8R (not for U.S.) - Assignment of the RJ45 Jack X3 (LAN

Connector)

RJ45 Jack X3

Signal Description Printed Circuit Con-

nector X2

1Tx+Transmit+ 1

2Tx–Transmit– 3

3 Rx + Receive + 7

4 – Not used

5 – Not used

6 Rx – Receive – 9

7 – Not used

8 – Not used
