Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-138 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
9.
7
Close the system.
CAUTION
Cuts caused by sharp edges on the shielding plate
When opening the system, ensure that you only touch the housing cover from the
outside.
10. Start the system by plugging in the power plug. If using a UPS, the battery voltage
must also be switched on.
Figure 3-49 SLAD16 - Installation of the Fan Kit in HiPath 3550
Step Activity
[B]
[D]
[A]
approx. 45
[C]
