Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-158 HiPath 3000/5000 V9, Service documentation

boards.fm

Peripheral boards

Touch guard

Front panel

CAUTION

Risk of electric shock through contact with live components

The boards are fitted with a touch guard because the onboard heat sinks are ener-

gized. Do not remove this touch guard.

Figure 3-57 SLMAE8, SLMAE - Touch Guard

Figure 3-58 SLMAE8, SLMAE - LEDs on the Front Panel

Two LEDs indicating the board status:

● LED (red)

● LED (green)
