Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-174 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
Table 3-77 SLMA/SLMA8 - Connector Panel Assignment with CHAMP Jack (for U.S. only)
CHAMP jack SLMA, SLMA8 Notes
1 1a 1 Ring
Port 1
26 1b 1 TIP
2 2a 2 Ring
Port 2
27 2b 2 TIP
3 3a 3 Ring
Port 3
28 3b 3 TIP
4 4a 4 Ring
Port 4
29 4b 4 TIP
5 5a 5 Ring
Port 5
30 5b 5 TIP
6 6a 6 Ring
Port 6
31 6b 6 TIP
7 7a 7 Ring
Port 7
32 7b 7 TIP
8 8a 8 Ring
Port 8
33 8b 8 TIP
9 9a 9 Ring
Port 9
Not used for
SLMA8
34 9b 9 TIP
10 10a 10 Ring
Port 10
35 10b 10 TIP
11 11a 11 Ring
Port 11
36 11b 11 TIP
12 12a 12 Ring
Port 12
37 12b 12 TIP
13 13a 13 Ring
Port 13
38 13b 13 TIP
14 14a 14 Ring
Port 14
39 14b 14 TIP
15 15a 15 Ring
Port 15
40 15b 15 TIP
16 16a 16 Ring
Port 16
41 16b 16 TIP
