boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-221
Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
Interface Assignments (for U.S. only)
Note: The STLS4 module supports the trunk side in Europe, so the transmit and receive signals
must be reversed before the first device on the S
0
bus.
The ISDN terminals must have their own local power supply.
The system assigns the MSN only after the S
0
port is configured on the “Euro bus” (not for U.S.)
and can be read out via the administration (Assistant T: Code 20 4 3 S
0
-Bus MSN).
Table 3-104 STLS4 Module Interface Assignments (for U.S. only)
Pin Port Assignment Pin Port Assignment
2 1 Transmit 2 3 Transmit
3 Receive 3 Receive
4 Receive 4 Receive
5 Transmit 5 Transmit
2 2 Transmit 2 4 Transmit
3 Receive 3 Receive
4 Receive 4 Receive
5 Transmit 5 Transmit
