A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-251

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Modem (optional)

The analog modem (modem kit F31505-E1-A147) is an optional submodule for the TCAS-2

and TCASR-2 cards, which is plugged into the X20 and X21 ports. This facilitates remote ad-

ministration of the CAS protocol converter on the TCAS-2 and TCASR-2 cards (see Page 3-

252).

Figure 3-83 TCAS-2, TCASR-2 (for selected countries only) – Optional Modem

X21: Pin1
