Siemens HiPath 3000 Series

To Next Page

To Previous Page

boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-261

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Table 3-122 TLA4R (not for U.S.) - Contact Assignments

MW8 jack X5, pin Trunk connections 1-4

1 14 a trunk 1

15 b trunk 1

2 24 a trunk 2

25 b trunk 2

3 34 a trunk 3

35 b trunk 3

4 44 a trunk 4

45 b trunk 4

MW8 jack X5, pin ALUM 1 + 2

5 54 TB1 ALUM1: Stn card connection

55 TA1

6 64 TB2 ALUM2: Stn card connection

65 TA2

7 74 BE1 ALUM1: Analog telephone

connection

75 AE1

8 84 BE2 ALUM2: Analog telephone

connection

85 AE2
